![Group image of panels from the KeTop OP 300 Keyboard series optimized for injection molding machines](https://a.storyblok.com/f/keba/media/industrial-automation/hmi/stationary/Header_KeTop-OP321-341.png/m/768x0)
KeTop OP 300キーボード
触知性かつ短いキーストロークを採用した固定型の操作デバイス
触知性フィードバックによるキーボード操作
OP 3x1シリーズの操作パネルは、ハイパフォーマンスなKePlast制御システムの構成要素です。標準的な油圧式射出成形機の操作に的を絞った製品です。キーボードに挿入可能なカードにより、個々の要件に合わせてキーを適応できるため、これらのパネルは他の各種産業にも適した信頼性の高い操作デバイスとなります。
OP 3x1キーボード操作パネルは、タッチスクリーン機能のない7インチ、8.4インチ、10.4インチ、および12.1インチのTFTカラーディスプレイを備えたモニターのみのソリューションとして提供されます。エンボス加工された短いストロークのキーで操作します。ビジュアリゼーションは、コントロールCPUで一元的に処理されます。堅牢さと業界で実証済みのエンジニアリングを組み合わせた金額に見合う価値をもたらす、費用対効果の高い設計です。
![最適化](http://a.storyblok.com/f/keba/media/icons/Center_Direction.png)
最適化
油圧式射出成形機向け
![個別化](http://a.storyblok.com/f/keba/media/icons/Fingerprint_Scan-50.png)
個別化
要件に合わせた調整
![理想的](http://a.storyblok.com/f/keba/media/icons/Expand.png)
理想的
7インチから12.1インチまでのディスプレイサイズ
![触知性](http://a.storyblok.com/f/keba/media/icons/Hand_Cursor.png)
触知性
エンボス加工された短いストロークのキー
技術仕様
KeTop | OP 321/C | OP 331/C bzw. /E | OP 341/C bzw. /E | OP 351/C | |||||
---|---|---|---|---|---|---|---|---|---|
Display | Display | ||||||||
Type | TFT | TFT | TFT | TFT | |||||
Size | 7" | 8.4" | 10.4" | 12.1“ | |||||
Resolution | 800 x 480 | 800 x 600 | 800 x 600 | 800 x 600 | |||||
Colors | 16.7 million | 256 | 256 | 256 | |||||
Operation elements | Operation elements | ||||||||
Embossed short-stroke keyboard with tactile feedback | 58 keys | 58 keys | 63 keys | 63 keys | |||||
Keys with LED | partial | partial | partial | partial | |||||
Insertable cards for keyboard | partial | partial (C) or complete (E) | partial (C) or complete (E) | partial | |||||
Cut-outs for emergency stop, USB and additional rotary switches | 4 | 4 | 5 | 5 |
ダウンロードとメディア
![Group picture of stationary operator panels of the OP 300 series](https://a.storyblok.com/f/40131/960x800/9d914e7eea/keplast_control_c1_technical-highlights_source.jpg/m/960x0)
注目点
- 低コストのキーボード操作
- 鮮明なディスプレイとハイエンドデザイン
- 挿入可能なカードによる簡単なカスタマイズ
